OLED Operation(Does not apply to the N7700PRO V2/N8800PRO V2/
N7710 series/N8810U series/N5550/N5810/N5810PRO/N4510U
series/N7510)
OLED Operation
The Thecus IP storage is equipped with an OLED on the front for easy status display
and setup. There are four buttons on the front panel to control the OLED functions.
OLED Controls
Use the Up (▲), Down (▼), Enter () and Escape (ESC) keys to select various
configuration settings and menu options for Thecus IP storage configuration.
The following table illustrates the keys on the front control panel:
Select the previous configuration settings option.
USB copy confirmation display.
Enter the selected menu option, sub-menu, or parameter setting.
Escape and return to the previous menu.
There are two modes of operation for the OLED: Display Mode and Management
Mode.
Display Mode
During normal operation, the OLED will be in Display Mode.
Current host name of the system.
Current WAN/LAN1 IP setting.
Current Link Aggregation status
Current system fan status.
The Thecus IP storage will rotate these messages every one-two seconds on the
OLED display.
USB Copy
The USB Copy function enables you to copy files stored on USB devices such as USB
disks and digital cameras to the Thecus IP storage with a press of a button. To use
USB copy, follow the steps below:
1. Plug your USB device into an available USB port on the Front Panel.
2. In Display Mode, press the Enter ().
You can also change your LCD password using the Web Administration
Interface by navigating to System Management > Administrator
Password. For more on the Web Administration Interface, see Chapter
4: System Management.
