130
If the other HA member is running smoothly, please choose Recovery HA to
complete HA recovery. Or select No, continue to let both HA members has they
are.
User and Group Authentication
The Thecus IP storage has built-in user database that allows administrators to
manage user access using different group policies. From the User and Group
Authentication menu, you can create, modify, and delete users, and assign them
to groups that you designate.
ADS/NT Support
If you have a Windows Active Directory Server (ADS) or Windows NT server to
handle the domain security in your network, you can simply enable the ADS/NT
support feature; the Thecus IP storage will connect with the ADS/NT server and get
all the information of the domain users and groups automatically. From the
Accounts menu, choose Authentication item and the ADS/NT Support screen
appears. You can change any of these items and press Apply to confirm your
settings.
A description of each item follows:
ADS/NT Support
WARNING
If there are transfers in progress when the
Primary server encounters problems and the
Secondary server becomes active, the session
will be stopped. Please contact your network
administrator to determine whether or not
your transfers were completed.
WARNING
When the original primary server rejoins the
HA environment, it will be updated with the
newer data from the secondary server to
synchronize for HA. Please be aware that the
data on the original primary server will be
replaced by the data from the secondary
server.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Thecus N7510 and is the answer not in the manual?

Thecus N7510 Specifications

General IconGeneral
RAID levels0, 1, 5, 6, 10, 50, JBOD
Hot-swap drive baysYes
Storage drive capacity- GB
Supported file systemsext3, ext4, XFS
Storage drive interfaceSerial ATA
Total installed storage capacity- TB
Number of storage drives installed-
Number of storage drives supported7
Internal memory2 GB
Internal memory typeDDR3
Processor familyIntel Atom®
Number of processors installed1
Data link protocolsTCP/IP/AppleTalk
Ethernet LAN data rates10, 100, 1000 Mbit/s
Maximum data transfer rate1000 Mbit/s
Supported network protocolsSMB/CIFS, HTTP/HTTPS, FTP, NFS v4, AFP
I/O ports1 x mic 1 x line-in 1 x audio out
Networking featuresGigabit Ethernet
Compatible operating systemsWindows 2000/XP/2003/Vista/ 7 UNIX/Linux Mac OS X
Security algorithms256-bit AES
Cables includedAC
USB 2.0 ports quantity4
Ethernet LAN (RJ-45) ports2
Bundled softwareAcronis True Image Thecus Backup Utility
Display typeLCD
Product colorBlack, Silver
Power supply unit (PSU) capacity300 W
Operating temperature (T-T)5 - 40 °C
Operating relative humidity (H-H)0 - 80 %
Sustainability certificatesRoHS
CertificationCE/FCC/C-Tick/VCCI/BSMI VMware, Citrix, WEEE
Weight and Dimensions IconWeight and Dimensions
Depth270 mm
Width210 mm
Height320 mm
Weight8400 g
