Thecus N7510 User Manual

131
Item
Description
Work Group / Domain
Name
Specifies the SMB/CIFS Work Group / ADS Domain Name (e.g.
MYGROUP).
ADS Support
Select Disable to disable authentication through Windows Active
Directory Server.
ADS Server Name
Specifies the ADS server name (e.g. adservername).
ADS Realm
Specifies the ADS realm (e.g. example.com).
Administrator ID
Enter the administrators ID of Windows Active Directory, which is
required for Thecus IP storage to join domain.
Administrator
Password
Enter the ADS Administrator password.
Apply
To save your settings.
To join an AD domain, you can refer
to the figure here and use the
example below to configure the
Thecus IP storage for associated filed
input:
AD Domain Example
Item
Information
Work Group / Domain
Name
domain
ADS Support
Enable
ADS Server Name
Computer1
ADS Realm
Domain.local
Administrator ID
Administrator
Administrator
Password
***********
NOTE
• The DNS server specified in the WAN/LAN1 configuration page should be
able to correctly resolve the ADS server name.
• The time zone setting between Thecus IP storage and ADS should be
identical.
• The system time difference between Thecus IP storage and ADS should
be less than five minutes.
• The Administrator Password field is for the password of ADS (Active
Directory Server) not Thecus IP storage.

Thecus N7510 Specifications

General

RAID levels	0, 1, 5, 6, 10, 50, JBOD
Hot-swap drive bays	Yes
Storage drive capacity	- GB
Supported file systems	ext3, ext4, XFS
Storage drive interface	Serial ATA
Total installed storage capacity	- TB
Number of storage drives installed	-
Number of storage drives supported	7
Internal memory	2 GB
Internal memory type	DDR3
Processor family	Intel Atom®
Number of processors installed	1
Data link protocols	TCP/IP/AppleTalk
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	SMB/CIFS, HTTP/HTTPS, FTP, NFS v4, AFP
I/O ports	1 x mic 1 x line-in 1 x audio out
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000/XP/2003/Vista/ 7 UNIX/Linux Mac OS X
Security algorithms	256-bit AES
Cables included	AC
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	2
Bundled software	Acronis True Image Thecus Backup Utility
Display type	LCD
Product color	Black, Silver
Power supply unit (PSU) capacity	300 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Sustainability certificates	RoHS
Certification	CE/FCC/C-Tick/VCCI/BSMI VMware, Citrix, WEEE

Weight and Dimensions

Depth	270 mm
Width	210 mm
Height	320 mm
Weight	8400 g
