N8800PRO V2/N8810U series:
The Thecus N8800PRO V2/N8810U series front panel has the device’s controls,
indicators, and hard disk trays:
Front Panel
Item
Description
1.Power Button
 Power on/off N8800PRO V2/N8810U series
2.Power LED
 Solid green: System is power on.
3.Reboot Button
 Press to system reboot
4.System fan alarm
LED
 Solid red: system fan failure notification
5. Mute button
 Mute the system fan alarm.
6.USB Port
USB 2.0 port for compatible USB devices, such as USB disks, USB
printers
7.Up Button ▲
 Push to scroll up when using the LCD display
8.Down Button ▼
 Push to enter USB copy operation screen
9.Enter Button 
 Push to enter LCD operate password for basic system setting
10.Escape Button
ESC
 Push to leave the current LCD menu
