4. If this RAID volume is meant to be the Master RAID volume, tick the Master
RAID checkbox.
5. Selected whether the RAID volume will be encrypted or not.
The RAID volume can protect data by using RAID Volume Encryption
function to prevent the risk of data exposure. To activate this function, the
Encryption option needs to be enabled while the RAID is created and
followed by a password input for identification. Also, an external writable
USB disk plugged into any USB port on the system is required to save the
password you have entered while the RAID volume is being created. See the
screenshot below for details.
Once the Create button has been pressed with the Encryption checkbox
enabled, the following message pop-up will appear for confirmation.
After the RAID volume has been created, you may remove the USB disk until
the next time the system boots. The RAID volume cannot be mounted if the
USB disk with the encryption key isn’t found in any system USB port when the
volume is accessed. To activate the encrypted volume, plug the USB disk
containing the encryption key and into any system USB port.
In a multiple RAID configuration, one RAID volume must be designated as the
Master RAID volume. The Master RAID volume will store all installed modules. If
the Master RAID is changed to another location (i.e. assigning volume 2 to be
the Master RAID volume after volume 1 had been previously assigned), then all
modules must be reinstalled. In addition, all system folders that were contained
on the Master RAID volume will be invisible. Reassigning this volume to be the
Master RAID will make these folders visible again.
