CUTMASTER 60i
Manual 0-5475 INTRODUCTION
2-3
3 Phase
60i 3 Phase Power Supply Specifications
Input Power 208 - 480 VAC(187 - 528 VAC), 3 Phase, 50/60 Hz
3 Phase Input Power Cable
Power Supply includes 9' single phase 12AWG 4/C input
cable without plug..
Output Current 10 - 60 Amps, Continuously Adjustable
Power Supply Gas Filtering
Ability
Particulates to 5 Microns
Maximum Inlet Pressure 125 PSI (8.6 bar)
60i Power Supply Duty Cycle *
Ambient Air Temperature
Duty Cycle Ratings @ 40° C (104° F)
Operating Range 0° - 50° C
Rating
All Units
Duty Cycle 50% 60% 100%
Current
60 Amps 50 Amps 40 Amps
DC Voltage
126 122 119
* NOTE: The duty cycle will be reduced if the primary input power (AC) is low or the
output voltage (DC) is higher than shown in this chart.
60i Cut Capacity
Recommended Pierce Maximum
5/8" 5/8" 1 1/4"
Generator Recommendations
When using generators to power the 60i Plasma Cutting System, the following ratings are a minimum and are to
be used along with the ratings listed above.
A60i Generator Specifications
Generator Output Rating 60i Output Current Arc Characteristic
15 kW 60A Full
12 kW
60A Limited
45A Full
10 kW
45A Limited
30A Full
NOTE!
Due to circuitry, age and condition two generators with the same ratings
may produce different results. Adjust the amperage accordingly.
