CUTMASTER 60i
Manual 0-5475 PARTS LIST
6-1
SECTION 6:
PARTS LISTS
6.01 Introduction
A. Parts List Breakdown
The parts list provide a breakdown of all replaceable components. The parts lists are arranged as follows:
6.03 Power Supply Replacement
6.04 Miscellaneous Replacement Power Supply Parts
6.05 Options and Accessories
6.06 External Replacement Parts (Plastic)
6.07 Internal Plastics Replacement Parts
6.08 Left Side Replacement Parts
6.09 Right Side Replacement Parts
6.10 Replacement Parts for SL60QD™ Hand Torch
6.11 Torch Consumable Parts (SL60 / SL60QD™)
6.12 Torch Consumable Parts SL100
NOTE!
Parts listed without item numbers are not shown, but may
be ordered by the catalog number shown.
B. Returns
If a product must be returned for service, contact your distributor. Materials returned without proper authorization
will not be accepted.
6.02 Ordering Information
Order replacement parts by catalog number and complete description of the part or assembly, as listed in the parts
list for each type item. Also include the model and serial number of the power supply. Address all inquiries to
your authorized distributor.
6.03 Power Supply Replacement
The following items are included with the replacement power supply: work cable & clamp, input power cable, gas
pressure regulator / filter, and operating manual.
Qty Description Catalog #
1 CutMaster
60i Power Supply
208/230 - 480VAC, SINGLE Phase, 60Hz,
with input power cable and plug for 208/230VAC 3-5630-1
208/230 - 480VAC, THREE Phase, 60Hz,
with input power cable and plug for 208/230VAC 3-5630-2
