THORLABS DC2200 User Manual

© 2020 Thorlabs GmbH66
DC2200
6 Appendix
6.1 Technical Data
Terminal LED1
Terminal LED2
Constant Current Mode
Current / Max. LED Forward Voltage
1.0 A / 50.0 V
2.0 A / 35.0 V
4.0 A / 15.0 V
5.0 A / 10.0 V
10.0 A / 5.0 V
1.5 A / 50.0 V
2.0 A / 35.0 V
Setting / Measurement Resolution (Display)
0.1 mA
Accuracy
Current Range 0.0 - 2.0 A
-
±(0.1% + 1 mA)
Current Range 0.0 - 4.0 A
±(0.1% + 2 mA)
-
Current Range 4.0 - 10.0 A
±(0.1% + 4 mA)
-
Noise and Ripple
(1 Hz - 10 MHz,
rms, typically)
Current Range 0.0 - 2.0 A
-
< 110 µA
Current Range 0.0 - 4.0 A
< 100 µA
-
Current Range 4.0 - 10.0 A
< 200 µA
-
Current Limit
Setting Resolution (Dis-
play)
Current Range 0.0 - 2.0 A
-
0.1 mA
Current Range 0.0 - 4.0 A
0.1 mA
-
Current Range 4.0 - 10.0 A
-
Accuracy
Current Range 0.0 - 2.0 A
-
±(0.12% + 1.6 mA)
Current Range 0.0 - 4.0 A
±(0.12% + 3 mA)
-
Current Range 4.0 - 10.0 A
±(0.12% + 6 mA)
-
Measurement
LED Current Resolution (Display)
0.1 mA
LED Current Accuracy
Current Range 0.0 - 2.0 A
-
±(0.1% + 1 mA)
Current Range 0.0 - 4.0 A
±(0.1% + 2 mA)
-
Current Range 4.0 - 10.0 A
±(0.1% + 4 mA)
-
LED Voltage Resolution
1
)
1 mV
LED Voltage Accuracy
1
)
±(0.5% + 100 mV)
PWM Mode
Frequency
0.1 Hz - 20 kHz
Duty Cycle
0.1 % to 99.9 %
Counts
1 to 1000; infinite
Pulse Mode
On Time
0.001 ms - 10 s
Off Time
0.001 ms - 10 s
Counts
1 to 1000; infinite
Internal Modulation Mode
Waveforms
Sine, Square, Triangle
Modulation Frequency Range
20 Hz - 100 kHz
