220 DCx camera
© 2010 Thorlabs
hCam
Camera handle
type
IS_SET_IMAGE_AOI
Sets an image AOI.
IS_GET_IMAGE_AOI
Returns the current image AOI.
IS_SET_AUTO_BRIGHT_AOI
Sets average AOI values for auto gain and auto shutter.
IS_GET_AUTO_BRIGHT_AOI
Returns the current auto brightness AOI.
IS_SET_AUTO_WB_AOI
Sets an auto white balance AOI.
IS_GET_AUTO_WB_AOI
Returns the current auto white balance AOI.
pXPos
Pointer to the horizontal position of the AOI
Returns the current setting when used together with
the IS_GET_... parameters.
0...XPosMax
| IS_SET_IMAGEPOS_X_ABS
Applies the absolute position to the memory as well.
pYPos
Pointer to the vertical position of the AOI
Returns the current setting when used together with
the IS_GET_... parameters.
0...YPosMax
| IS_SET_IMAGEPOS_Y_ABS
Applies the absolute position to the memory as well.
pWidth
Pointer to the width of the AOI
Returns the current setting when used together with
the IS_GET_... parameters.
pHeight
Pointer to the height of the AOI
Returns the current setting when used together with
the IS_GET_... parameters.
Return Values
IS_SUCCESS
Function executed successfully
IS_NO_SUCCESS
General error message
Related Functions
is_SetImagePos()
is_SetBinning()
is_SetSubSampling()
is_SetAutoParameter()
271
231
284
221
