THORLABS DCU22 Series User Manual

387Appendices
© 2010 Thorlabs
10.1.1
Common Data
Table 15: Camera Specifications
DCC
DCU
Weight
32
74
g
Dimension with housing
(WxHxD)
44 x 48,6 x 25,7
32 x 34 x 48,3
mm
Lens mount
CS-Mount
SM1-Mount
C-Mount
SM1-Mount
Interface
USB 2.0
Max. cable length
5
m
Max. cameras
127
*1)
Camera ID
1-254
Fulfilled ordinance
CE Class A
*1) Maximum is 127 USB devices, Hubs included.
10.1.1.1
Ambient specification
Table16: Ambient specification
Min.
Max.
Operating temperature
0
50
°C
Storage temperature
-20
60
°C
Operating relative humidity
*1)
20
80
%
Storage relative humidity
*1)
20
85
%
*1) Non condensing.
Non-condensing means that the relative air humidity must be below 100%. Otherwise, moisture will
form on the camera surface. If, for example, air has a relative humidity of 40% at 35°C, the relative
humidity will increase to over 100% if the air cools down to 19.5°C; condensation begins to form.
NOTE
Avoid high air humidity levels and rapid temperature changes when using DCx
cameras.
Vibration and shock resistance
Vibration and shock resistance of the DCx cameras were tested as specified in DIN EN 60068-2-6
(1996-05), DIN EN 60068-2-27(1995-03) and DIN EN 60068-2-29(1995-03). The mechanical shock
was at 80 g; the vibration testing was performed with sinusoidal vibration at a frequency between 30
