Page #411 background imageLoading...
Page #411 background image
406 DCx camera
© 2010 Thorlabs
10.1.5.3
DCU223x
Table 25: Sensor specifications of the DCU 223x
Sensor type
CCD
Exposure mode
Electronic global shutter
Read out mode
Progressive scan
Resolution
1024 x 768 Pixel
Optical sensor class
1/3 "
Exact sensitive area
4.76 mm x 3.57 mm
Exact optical sensor diagonal
6.0 mm, 0.24“
Pixel size
4.65 µm, square
Sensor name monochrome camera
Sony ICX204AL
Sensor name color camera
Sony ICX204AK
Pixel clock range
5 – 30 MHz
*1
Frame rate, freerun mode
30 fps
*2
Frame rate, trigger mode, 1ms exposure time
27 fps
*2
Exposure time in freerun mode
0.066 ms
*2
– 1040 ms
*3
Exposure time in trigger mode
0.066 ms
*2
– 10 minutes
*3
Binning
vertical
*4
Mode
Monochrome
Factor, maximum resolution, frame rate
2x, 1280 x 384 Pixel, 53 fps
Factor, maximum resolution, frame rate
4x, 1280 x 192 Pixel, 85 fps
Subsampling
-
AOI
horizontal, vertical
*4
Frame rate bei 320 x 240 pixel (CIF)
78 fps
Absolute image width, step width
16 – 1024 Pixel, 16
Absolute image height, step width, monochrome
120 – 768 Pixel, 1
Absolute image height, step width, color model
120 – 768 Pixel, 2
Position raster horizontal, monochrome
1
Position raster horizontal, color model
2
Position raster vertical, monochrome
1
Position raster vertical, color model
2
Gain
Monochrome model
Master
Color model
Master, RGB
