408 DCx camera
© 2010 Thorlabs
10.1.5.4
DCC1545M
Table 26: Sensor specifications of the DCC 1545M
Sensor specification
Sensor type
CMOS
Shutter system
Electronic rolling shutter
Readout mode
Progressive scan
Resolution class
SXGA
Resolution
1280 x 1024 pixels (1.3 Mpixels)
Aspect ratio
5:4
Pixel depth
8 bits
ADC resolution (internal)
10 bits
Optical sensor class
1/2 inch
Exact sensitive area
6.66 x 5.32 mm
Exact optical sensor diagonal
8.5 mm (1/1.9 inch)
Pixel size
5.2 µm, square
Sensor name, monochrome
Micron MT9M001
Gain
Monochrome model (master gain)
13x
Offset control, mode
Auto/manual, additive
Gain boost
1.5x
Camera timing
Pixel clock range
MHz
5-43
*1)
Pixel clock range (with subsampling/binning)
MHz
5-50
*1)
Frame rate (freerun mode)
fps
25
*2)
Frame rate (trigger mode, 1 ms exposure)
fps
23
*2)
Exposure time in freerun mode
ms
0.035 *
2)
-980
*3)
Exposure time in trigger mode
ms
0.035 *
2)
-980
*3)
AOI
Mode
Horizontal
*4)
+ Vertical
*4)
AOI image width, step width
Pixels
32 - 1280, 4
AOI image height, step width
Pixels
4 - 1024, 2
AOI position grid horizontal, vertical
Pixels
4, 2
AOI frame rate, 1024 x 768 pixels (XGA)
fps
39
AOI frame rate, 640 x 480 pixels (VGA)
fps
84
AOI frame rate, 320 x 240 pixels (CIF)
fps
231
Binning
Mode
-
