Page #358 background image
353SDK (Software development Kit)
© 2010 Thorlabs
Parameter
Description
Value range
Example
IS_CM_RGBA8_PACKED
Colour format
0, 1, 2, 4, (8
3)
)
2
IS_CM_RGB8_PACKED
Colour format
0, 1, 2, 4, (8
3)
)
2
IS_CM_RGBY8_PACKED
Colour format
0, 1, 2, 4, (8
3)
)
8
IS_CM_RGB10V2_PACKED
Colour format
0, 1, 2, 4, (8
3)
)
8
[Parameters]
Additional image parameter settings
Colormode
Sets the current colour mode
see Color and
Memory Formats
11
Brightness
Software correction of image
brightness
X)
0...255
100
Contrast
Software correction of image
contrast
X)
0...511
215
Gamma
Software correction of the
gamma value
0.01...10.0
1.000000
Hardware Gamma
Sensor-based hardware
correction of the gamma
value
0, 1
0
Blacklevel Mode
Mode for black level
correction of the sensor
0, 1, 32
2)
1
Blacklevel Offset
Manual offset for black level
correction of the sensor
0...255
0
Hotpixel Mode
Mode for hot pixel correction
0, 1, 2, 4
2)
2
Hotpixel Threshold
Not used
-
0
GlobalShutter
Enables the Global Start
shutter of the sensor
0, 1
0
[Gain]
Sets the sensor gain control for image brightness
Master
Master gain
0...100
0
Red
Red gain
0...100
6
Green
Green gain
0...100
0
Blue
Blue gain
0...100
6
GainBoost
Activate gain boost
0 , 1
0
[Processing]
Parameters for image pre-processing in the driver
EdgeEnhancement
Enable edge enhancement
0...2
0
RopEffect
Image geometry change
(Rop = raster operation), e.g.
mirroring
0, 8, 16, 32, 64
2)
0
350
