4 External Connections ITC8xxxDS15
21
4.6 Connecting a TEC Element - ITC8000DS15
The TEC element is connected between pins 7 (plus pole) and pins 8 (minus pole).
Connecting a TEC Element
Attention
An reverse poled TEC element may lead to a thermal runaway and destruction of the connected
components. Please refer to section Polarity Check of the TEC Element .
