THORLABS ITC8000 - Reading the TEC Voltage (VTE)

© 2016 Thorlabs52
ITC8000
7.3.28 Reading the TEC Voltage (VTE)
Command
Explanation
Response Example
Programming
":VTE:MEAS <NR1>"
Programs TEC (or heater) voltage to be the measurement value
for “ELCH
1
)” on position <NR1> (1...8) in the output string.
Reading
":VTE:ACT?"
Reads the actual TEC (or heater) voltage
[:VTE:ACT <NR3><LF>]
":VTE:MIN_R?"
Reads the minimum UTE - ADC = 0000
[:VTE:MIN_R <NR3><LF>]
":VTE:MAX_R?"
Reads the maximum UTE - ADC = FFFF
[:VTE:MAX_R <NR3><LF>]
":VTE:MEAS?"
Reads the position of the TEC voltage as measurement value in
the “ELCH” output string (1....8, 0 if not selected)
[:VTE:MEAS <NR1><LF>]
1
) ELectrical CHaracterization
