© 2016 Thorlabs
7 Communication with a PC
41
7.3.10 Setting the Monitor Diode Current (IMD)
Command
Explanation
Response Example
Programming
":IMD:SET <NR3>"
Programs the monitor diode set current
":IMD:START <NR3>"
Programs the monitor diode start current forELCH *)
":IMD:STOP <NR3>"
Programs the monitor diode stop current for “ELCH
":IMD:MEAS <NR1>"
Programs the monitor diode current as measurement value in the
“ELCH output string on position <NR1> (1....8)
Reading
":IMD:SET?"
Reads the monitor diode set current
[:IMD:SET <NR3><LF>]
":IMD:ACT?"
Reads the actual monitor diode current
[:IMD:ACT <NR3><LF>]
":IMD:MIN?"
Reads allowed minimum monitor diode set current
[:IMD:MIN <NR3><LF>]
":IMD:MAX?"
Reads allowed maximum monitor diode set current
[:IMD:MAX <NR3><LF>]
":IMD:MIN_W?"
Reads minimum monitor diode current for IPD - DAC = 0000
[:IMD:MIN_W <NR3><LF>]
":IMD:MAX_W?"
Reads maximum monitor diode current for IPD - DAC = FFFF
[:IMD:MAX_W <NR3><LF>]
":IMD:MIN_R?"
Reads minimum monitor diode current for IPD - ADC = 0000
[:IMD:MIN_R <NR3><LF>]
":IMD:MAX_R?"
Reads maximum monitor diode current for IPD - ADC = FFFF
[:IMD:MAX_R <NR3><LF>]
":IMD:START?"
Reads the monitor diode start current for “ELCH”
[:IMD:START <NR3><LF>]
":IMD:STOP?"
Reads the monitor diode stop current for “ELCH”
[:IMD:STOP <NR3><LF>]
":IMD:MEAS?"
Reads the position of the monitor diode current as measurement
value in theELCHoutput string (1....8, 0 if not selected)
[:IMD:MEAS <NR1><LF>]
*) ELCH = ELectrical CHaracterization, a PRO8000 Macro Function. Please see the PRO8000 Series Mainframe
Manual for details.
