© 2016 Thorlabs40
ITC8000
7.3.9 Setting the Laser Diode Current (ILD)
Explanation
Response Example
Programs the laser diode set current
Programs the laser diode start current for “ELCH” *)
Programs the laser diode stop current for “ELCH”
Programs the laser diode current as measurement value on
position <NR1> in the output string for “ELCH”
(<NR1> = 1....8)
Reads the laser diode set current
[:ILD:SET <NR3><LF>]
Reads the actual laser diode current
[:ILD:ACT <NR3><LF>]
Reads the allowed minimum laser diode current
[:ILD:MIN <NR3><LF>]
Reads the allowed maximum laser diode current
[:ILD:MAX <NR3><LF>]
Reads the minimum laser diode current for ILD - DAC = 0000
[:ILD:MIN_W <NR3><LF>]
Reads the maximum laser diode current for ILD - DAC = FFFF
[:ILD:MAX_W <NR3><LF>]
Reads the minimum laser diode current for ILD - ADC = 0000
[:ILD:MIN_R <NR3><LF>]
Reads the maximum laser diode current for ILD - ADC = FFFF
[:ILD:MAX_R <NR3><LF>"]
Reads the laser diode start current for “ELCH”
[:ILD:START <NR3><LF>]
Reads the laser diode stop current for “ELCH”
[:ILD:STOP <NR3><LF>]
Reads the position of the laser diode current as measurement
value in the output string for “ELCH” (1....8, 0 if not selected)
[:ILD:MEAS <NR1><LF>]
*) ELCH = ELectrical CHaracterization, a PRO8000 Macro Function. Please see the PRO8000 Series Mainframe
Manual for details.
