7 Communication with a PC
47
7.3.20 Selecting the Sensor (SENS)
Explanation
Response Example
Sensor: AD590 / LM335 Series
Reads the actual sensor type
[:SENS AD<LF>]
[:SENS TH<LF>]
7.3.21 Programming the Resistance of the Temperature Sensor (RESI)
Explanation
Response Example
Programs the set resistance of the temperature sensor
(thermistor, Pt-100, Pt-1000)
Programs RESI to be the measurement value for “ELCH
1
)” on
position <NR1> (1...8) in the output string.
Reads the set resistance of the temperature sensor
[:RESI:SET <NR3><LF>]
Reads the actual resistance of the temperature sensor
[:RESI:ACT <NR3><LF>]
Reads the minimum allowed set resistance of the sensor
[:RESI:MIN <NR3><LF>]
Reads the maximum allowed set resistance of the sensor
[:RESI:MAX <NR3><LF>]
Reads R - DAC = 0000
[:RESI:MIN_W <NR3><LF>]
Reads R - DAC = FFFF
[:RESI:MAX_W <NR3><LF>]
Reads R - ADC = 0000
[:RESI:MIN_R <NR3><LF>]
Reads R - ADC = FFFF
[:RESI:MAX_R <NR3><LF>]
Reads the position of R as measurement value in the “ELCH”
output string (1....8, 0 if not selected)
[:RESI:MEAS <NR1><LF>]
1
) ELectrical CHaracterization
