© 2016 Thorlabs64
ITC8000
9 Appendix
9.1 Technical Data
All technical data are valid at 23 ± 5°C and 45 ± 15% rel. humidity (non condensing)
Parameter
ITC8022
ITC8052
ITC8102
Laser Controller: Current Control
Laser Current Control Range
0 to ± 200 mA
0 to ± 500 mA
0 to ± 1 A
Compliance Voltage
> 5 V
Setting Resolution
3 µA
7.5 µA
15 µA
Accuracy (Full Scale)
± 0.05 %
± 0.05 %
± 0.1 %
Noise w/o Ripple (10Hz to 10MHz, rms, typ.)
< 2 µA
< 5 µA
< 10 µA
Ripple (50 Hz, rms, typ.)
< 1 µA
< 1 µA
< 1.5 µA
Transients (processor, typ.)
< 15 µA
< 30 µA
< 50 µA
Transients (other, typ.)
< 200 µA
< 500 µA
< 1 mA
Drift (24hrs, at const. ambient temperature, typ.)
< 3 µA
< 10 µA
< 25 µA
Temperature Coefficient
< 50 ppm/ °C
Laser Controller: Current Limit
Setting Range
Resolution
6 µA
15 µA
30 µA
Accuracy
± 200 µA
± 500 µA
± 2 mA
Laser Controller: Power Control
Monitor Current IPD Range
10 µA to 2 mA
1
)
Resolution
30 nA
Setting Accuracy
±0.1% f.s. (typ.)
Drift (30 min., at constant the ambient temperature)
Monitor Diode BIAS Voltage
0 to 10 V (adjustable)
Laser Voltage Measurement
Measurement principle
4-wire
Measurement range
0 to 10 V
Resolution
0.3 mV
Accuracy
± 5 mV
