Page #44 background imageLoading...
Page #44 background image
© 2016 Thorlabs42
ITC8000
7.3.11 Calibrating a Photodiode (CALPD)
Command
Explanation
Response Example
Programming
":CALPD:SET <NR3>"
Programs the sensitivity calibration factor (h) of the monitor
diode in [A/W]
Reading
":CALPD:SET?"
Reads the sensitivity (h) of the monitor diode in [A/W]
[:CALPD:SET <NR3><LF>]
":CALPD:MIN?"
Reads the minimum allowed sensitivity (h) of the module
[:CALPD:MIN <NR3><LF>]
":CALPD:MAX?"
Reads the maximum allowed sensitivity (h) of the module
[:CALPD:MAX <NR3><LF>]
7.3.12 Programming the Optical Power (POPT)
Command
Explanation
Response Example
Programming
":POPT:SET <NR3>"
Programs the laser diode set current
Reading
":POPT:SET?"
Reads the optical power
[:POPT:SET <NR3><LF>]
":POPT:ACT?"
Reads the actual optical power
[:POPT:ACT <NR3><LF>]
":POPT:MIN?"
Reads the minimum possible optical power
[:POPT:MIN <NR3><LF>]
":POPT:MAX?"
Reads the maximum possible optical power
[:POPT:MAX <NR3><LF>]
":POPT:MIN_W?"
Reads the optical power for PLD - DAC = 0000
[:POPT:MIN_W <NR3><LF>]
":POPT:MAX_W?"
Reads the optical power for PLD - DAC = FFFF
[:POPT:MAX_W <NR3><LF>]
":POPT:MIN_R?"
Reads the optical power for PLD - ADC = 0000
[:POPT:MIN_R <NR3><LF>]
":POPT:MAX_R?"
Reads the optical power for PLD - ADC = FFFF
[:POPT:MAX_R <NR3><LF>"]
