Page #48 background imageLoading...
Page #48 background image
© 2016 Thorlabs46
ITC8000
7.3.18 Programming the Temperature Window (TWIN)
Command
Explanation
Response Example
Programming
":TWIN:SET <NR3>"
Programs the temperature window.
Reading
":TWIN:SET?"
Reads the temperature window.
[:TWIN:SET <NR3><LF>]
":TWIN:MIN?"
Reads the minimum allowed temperature window.
[:TWIN:MIN <NR3><LF>]
":TWIN:MAX?"
Reads the maximum allowed temperature window.
[:TWIN:MAX <NR3><LF>]
":TWIN:MIN_W?"
Reads TWIN - DAC = 0000
[:TWIN:MIN_W <NR3><LF>]
":TWIN:MAX_W?"
Reads RWIN - DAC = FFFF
[:RWIN:MAX_W <NR3><LF>]
7.3.19 Programming the Resistance Window (RWIN)
Command
Explanation
Response Example
Programming
":RWIN:SET <NR3>"
Programs the resistance window.
Reading
":RWIN:SET?"
Reads the set resistance window.
[:RWIN:SET <NR3><LF>]
":RWIN:MIN?"
Reads the minimum allowed set resistance window.
[:RWIN:MIN <NR3><LF>]
":RWIN:MAX?"
Reads the maximum allowed set resistance window.
[:RWIN:MAX <NR3><LF>]
":RWIN:MIN_W?"
Reads RWIN - DAC = 0000
[:RWIN:MIN_W <NR3><LF>]
":RWIN:MAX_W?"
Reads RWIN - DAC = FFFF
[:RWIN:MAX_W <NR3><LF>]
