THORLABS ITC8000 - Programming the PID Shares (SHAREP, SHAREI, SHARED); Switching the I Share on; off (INTEG)

© 2016 Thorlabs50
ITC8000
7.3.24 Programming the PID Shares (SHAREP, SHAREI, SHARED)
Command
Explanation
Response Example
Programming
":SHAREP:SET <NR3>"
Programs the P share
":SHAREI:SET <NR3>"
Programs the I share
":SHARED:SET <NR3>"
Programs the D share
Reading
":SHAREP:SET?"
Reads the P share
[:SHAREP:SET <NR3><LF>]
":SHAREI:SET?"
Reads the I share
[:SHAREI:SET <NR3><LF>]
":SHARED:SET?"
Reads the D share
[:SHARED:SET <NR3><LF>]
":SHAREP:MIN?"
Reads the minimum allowed P share
[:SHAREP:MIN <NR3><LF>]
":SHAREI:MIN?"
Reads the minimum allowed I share
[:SHAREI:MIN <NR3><LF>]
":SHARED:MIN?"
Reads the minimum allowed D share
[:SHARED:MIN <NR3><LF>]
":SHAREP:MAX?"
Reads the maximum allowed P share
[:SHAREP:MAX <NR3><LF>]
":SHAREI:MAX?"
Reads the maximum allowed I share
[:SHAREI:MAX <NR3><LF>]
":SHARED:MAX?"
Reads the maximum allowed D share
[:SHARED:MAX <NR3><LF>]
Please see also PID Adjustment .
7.3.25 Switching the I Share On / Off (INTEG)
Command
Explanation
Response Example
Programming
":INTEG ON"
Switches the I share on
":INTEG OFF"
Switches the I share off
Reading
":INTEG?"
Reads the status of the I share
[:INTEG ON<LF>]
[:INTEG OFF<LF>]
23
