© 2016 Thorlabs
9 Appendix
65
Temperature Controller: Output
TEC Current Control Range
-2 to +2 A
Compliance Voltage
> 8 V
Maximum Output Power
16 W
Measurement Resolution TEC Current
0.07 mA
Measurement Resolution TEC Voltage
0.3 mV
Noise and Ripple (typ.)
< 1 mA
Temperature Controller: Current Limit
Setting Range
Resolution
0.5 mA
Setting Accuracy
± 20 mA
AD590 / AD592 / LM335 IC Sensors
Control Range
-12.375 °C ... +90.000 °C
Measurement Accuracy
±0.1 °C
Measurement Resolution
0.0015 °C
Setting Accuracy
±0.1 °C
Setting Resolution
0.0015 °C
Temperature Stability (24h, typ.)
< 0.001 °C
Thermistor (Calibrated / Not Calibrated, Temperature Display in W )
Measurement Current
50 µA
Control Range
200 W to 40 kW (10 kW nom. resistance at 25°C)
Resolution
0.7 W
Setting Accuracy
±10 W
Resistance Stability (24h, typ.)
< 1 W
Thermistor (Calibrated, Temperature Display in °C)
Measurement Current
50 µA
1
)
Control Range
Temperature at 40 kW to 150 °C
2
)
Resolution
2
)
Setting Accuracy
2
)
Temperature Stability (24h, typ.)
2
)
Temperature Control Loop
P, I and D Shares
To Be Set Separately
Setting Range
2.5 to 100 %
General
Warm-up Time for Rated Accuracy
Module Width
1 Slot
Operating Temperature Range
0 - 40 °C
Storage Temperature Range
-40 to 70 °C
Output Connector
LD
TEC
D-Sub 9 Pin, Female
D-Sub 15 Pin, Female
1
) Other ranges on request
2
) Depending on Thermistor Specification
