THORLABS PAX1000 User Manual

© 2019 Thorlabs GmbH5
PAX1000
2 Getting Started
2.1 Parts List
Inspect the shipping container for damage.
If the shipping container seems to be damaged, keep it until you have inspected the contents
and you have inspected the PAX1000 mechanically and electrically.
Verify that you have received the following items within the package, depending on the ordered
item:
1. PAX1000VIS (PAX1000VIS/M) Polarimeter, Wavelength Range 400 – 700 nm
2. F240FC-A Fiber Collimator
3. KAD12F SM1 Threaded Adapter for the Fiber Collimator
4. SM1M10 SM1 Lens Tube
5. SM1CP1 End Cap (Modified: Laser-Engraved Cross-Hair)
6. Cable USB 2.0, A to Mini-B, 1.5 m length
7. Power Supply DS15
8. Quick Reference Manual
or
1. PAX1000IR1 (PAX1000IR1/M) Polarimeter, Wavelength Range 600 to 1080 nm
2. F240FC-B Fiber Collimator
3. KAD12F SM1 Threaded Adapter for the Fiber Collimator
4. SM1M10 SM1 Lens Tube
5. VRC2SM1 with mounting adapter
6. Cable USB 2.0, A to Mini-B, 1.5 m length
7. Power Supply DS15
8. Quick Reference Manual
or
1. PAX1000IR2 (PAX1000IR2/M) Polarimeter, Wavelength Range 900 to 1700 nm
2. F240FC-C Fiber Collimator
3. KAD12F SM1 Threaded Adapter for the Fiber Collimator
4. SM1M10 SM1 Lens Tube
5. VRC2SM1 with mounting adapter
6. Cable USB 2.0, A to Mini-B, 1.5 m length
7. Power Supply DS15
8. Quick Reference Manual
