9 Appendix
9.1 Technical Data
Optical Parameters
1
)
Wavelength Range
PAX1000VIS
PAX1000IR1
PAX1000IR2
400 nm to 700 nm
600 nm to 1080 nm
900 nm to 1700 nm
Dynamic Range
-60 dBm to +10 dBm
Sampling Rate
Maximum
2
)
Default
400 Samples / s
30 Samples / s
Measurable SOP States
full Poincaré Sphere
Azimuth Accuracy
3
)
±0.25 °
Ellipticity Accuracy
±0.25 °
DOP Accuracy
±1.0 %
Input Fiber Connector
FC/PC
Free Space Aperture
Ø 3mm
Maximum Input Beam Divergence
2 °
General
Interface
USB 2.0
Power Supply
Via USB interface
External Power Supply 15.0 V / 1.2 A DC
4
)
Operating Temperature Range
5
)
+5 to +40 °C
Storage Temperature Range
-40 to +70 °C
Dimensions (W x H x D)
51.0 mm x 55.0 mm x 56.3 mm
(2.01 in x 2.17 in x 2.22 in)
Weight
0.28 kg
Warm-up time for rated accuracy
15 min
1
) All polarization specifications are valid for power range from -40 dBm to +3 dBm.
2
) One sample per half turn and 200 Hz motor drive speed; with connected external power supply.
3
) For any SOP with -30° < ellipticity < 30°.
4
) Required for high-speed measurements; included with the PAX1000
5
) non-condensing
All technical data are valid at 23 ± 5°C and 45 ± 15% rel. humidity (non condensing).
