TC300 Heater Temperature Controller Chapter 8: Command Line Operation
Page 40 CTN017856-D02
Query I share (Gain of I) value of PID for Channel 1, range: 0 to 9.99, resolution: 0.01.
Return:
n/100
TI2=n
Set I share (Gain of I) value of PID for Channel 2 to n/100. The range of n is 0 to 999 with a resolution of 1.
TI2?
Query I share (Gain of I) value of PID for Channel 2, range: 0 to 9.99, resolution: 0.01.
Return:
n/100
8.3.28. TD 1=n; TD 1?; TD 2=n; TD 2? – TD Value of PID
TD command is used to set and query the D share (Gain of D) value of PID.
TD1=n
Set D share (Gain of D) value of PID for Channel 1 to n/100. The range of n is 0 to 999 with a resolution of 1.
TD1?
Query D share (Gain of D) value of PID for Channel 1, range: 0 to 9.99, resolution: 0.01.
Return:
n
TD2=n
Set D share (Gain of D) value of PID for Channel 2 to n/100. The range of n is 0 to 999 with a resolution of 1.
TD2?
Query D share (Gain of D) value of PID for Channel 1, range: 0 to 9.99, resolution: 0.01.
Return:
n
8.3.29. PERIOD1=n; PERIOD1?; PERIOD2=n; PERIOD2? – PERIOD Value of PID
PERIOD command is used to set and query the PERIOD value of PID, the range is from 100 to 5000 ms.
PERIOD1=n
Set PERIOD value of PID for Channel 1, range:100 to 5000 ms, resolution: 1 ms
PERIOD1?
Query PERIOD value of PID for Channel 1
Return:
n
PERIOD2=n
Set PERIOD value of PID for Channel 2, range:100 to 5000 ms, resolution: 1 ms
PERIOD2?
Query PERIOD value of PID for Channel 2
Return:
n
8.3.30. PID1DEF!; PID2DEF! – Load Default PID Parameters
These commands are used to load default PID parameters of TC300.
PID1DEF!
