TC300 Heater Temperature Controller Chapter 11: Specifications
Rev B, January 5, 2022 Page 47
Chapter 11 Specifications
Specifications Value
Max Output Power per Channel 48 W
Max Output Current per Channel 2 A
Max Output Voltage per Channel 24 V
Temperature Setting Range Sensor dependent, -200 to 400 °C Max
Set Point Resolution 0.1 °C
Temperature Stability
±0.1 °C
Sensor Types
Thermistor, AD590, Thermocouple,
2-Wire and 4-Wire Platinum 100 Ω,
2-Wire and 4-Wire Platinum 1000 Ω
Output Connector Type Hirose HR10A-7R-6S(73)
USB Interface USB 2.0, Standard B
Power Supply 100 – 240 VAC, 50 – 60 Hz, 165 VA Max
Operating Temperature 0 – 40 °C
Storage Temperature -15 – 65 °C
Dimensions (H x W x D)
86.1 mm x 154.2 mm x 327.8 mm
(3.39” x 6.07” x 12.91”)
Weight 1.8 kg
