© 2007-2012 Thorlabs GmbH
6 WFS Series
applications requiring different WFS specifications in terms of spatial resolution
(lenslet pitch), focal length, wavefront sensitivity and dynamic range. See chapter
Microlens Data for a table of available MLAs.
Available wavefront sensor types (Order Codes)
WFS150-5C Wavefront Sensor, Chrome Apertures 300-1100 nm, pitch=150 µm
WFS150-7AR Wavefront Sensor, AR Coated 400-900 nm, pitch=150µm
WFS300-14AR Wavefront Sensor, AR Coated 400-900 nm, pitch=300 µm
WFS10-5C Fast Wavefront Sensor, Chrome Apertures 300-1100 nm,
pitch=150 µm
WFS10-7AR Fast Wavefront Sensor, AR Coated 400-900 nm, pitch=150µm
WFS10-14AR Fast Wavefront Sensor, AR Coated 400-900 nm, pitch=300 µm
All Thorlabs Wavefront Sensors are equipped with an easily exchangeable lenslet
array.
Available WFS kits with 2 MLA
You may order also a WFS Wavefront Sensor calibrated with two included microlens
arrays:
Type
Used camera
Included micro lens arrays
WFS-K1
WFS150 (CCD)
Chrome Mask 300-1100 nm, pitch=150 µm
AR Coated 400-900 nm, pitch=300 µm
WFS-K2
WFS150 (CCD)
AR Coated 400-900 nm, pitch=150µm
AR Coated 400-900 nm, pitch=300 µm
WFS10-K1
WFS10 (CMOS)
Chrome Mask 300-1100 nm, pitch=150 µm
AR Coated 400-900 nm, pitch=300 µm
WFS10-K2
WFS10 (CMOS)
AR Coated 400-900 nm, pitch=150µm
AR Coated 400-900 nm, pitch=300 µm
Wavefront Sensor types and kits as stated above are factory calibrated. For other
than above mentioned combinations, please contact your local Thorlabs office (see
Addresses )
Three Wavefront Sensor Models
There are three different versions available which differ in the type of implemented
microlens array (MLA, see data here Microlens Data ) and its distance to the
CCD camera sensor.
WFS150-5C / WFS10-5C uses a MLA with a chrome mask on it that prevents
light going in between the microlenses directly to the CCD detector. This
increases the image contrast of the detected spotfield and improves the
instrument accuracy, especially in case of strong wavefront deformations. The
wavelength range is not restricted by an AR coating and covers the full
sensitivity range of the Silicon CCD detector 300 - 1100 nm (with largely
reduced sensitivity at the edges). Take into account that such a chrome mask
