Description Parameter Unit Setting range
Timer 17 s
0 ... 59 step = 1
60 ... 3540 step = 60
3600 ... 86400 step = 600
Timer 18
s
0 ... 59 step = 1
60 ... 3540 step = 60
3600 ... 86400 step = 600
Timer 19
s
0 ... 59 step = 1
60 ... 3540 step = 60
3600 ... 86400 step = 600
Timer 20
s
0 ... 59 step = 1
60 ... 3540 step = 60
3600 ... 86400 step = 600
Timer 21
s
0 ... 59 step = 1
60 ... 3540 step = 60
3600 ... 86400 step = 600
Timer 22
s
0 ... 59 step = 1
60 ... 3540 step = 60
3600 ... 86400 step = 600
Timer 23
s
0 ... 59 step = 1
60 ... 3540 step = 60
3600 ... 86400 step = 600
Timer 24
s
0 ... 59 step = 1
60 ... 3540 step = 60
3600 ... 86400 step = 600
ARF - 1
Enable
OFF | ON
Selection
Aux1 | Aux2
Up frequency limit
Hz 50.00 ... 60.00 step = 0.05
Low frequency limit
Hz 40.00 ... 50.00 step = 0.05
Up frequency band limit
Hz 50.00 ... 60.00 step = 0.05
Low frequency band limit
Hz 40.00 ... 50.00 step = 0.05
Timer
s
0 ... 59 step = 1
60 ... 1000 step = 10
ARF - 2
Enable
OFF | ON
Selection
Aux1 | Aux2
Up frequency limit
Hz 50.00 ... 60.00 step = 0.05
Low frequency limit
Hz 40.00 ... 50.00 step = 0.05
Up frequency band limit
Hz 50.00 ... 60.00 step = 0.05
Low frequency band limit
Hz 40.00 ... 50.00 step = 0.05
Timer
s
0 ... 59 step = 1
60 ... 1000 step = 10
Circuit Breaker supervision
LEDs-relays allocation
Open CB command relays CBopen-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Close CB command relays CBclose-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
CB Closed LEDs CBclose-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8
| L9 | L10
CB Open LEDs CBopen-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8
| L9 | L10
CB State diagnostic relays CBdiag-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
CB Diagnostic
Number of CB trips mode ModeN.Open
OFF | ON
Number of CB trips threshold N.Open
0 ... 10000 step = 1
CB operating time mode Mode-tOpen
OFF | ON
