Description Parameter Unit Setting range
Trigger relay for CB opening time trigger measurement Ktrig-break K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Circuit breaker maximum allowed opening time
Value
s 0.05 ... 1.00 step = 0.01
Number of CB trips diagnostic relays N.Open-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Circuit breaker opening time diagnostic relays tbreak-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Number of CB trips diagnostic LEDs N.Open-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8
| L9 | L10
Circuit breaker opening time diagnostic LEDs tbreak-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8
| L9 | L10
Remote tripping
Remote tripping breaker failure RemTrBF
OFF | ON
Remote tripping relays RemTrip-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Remote tripping LEDs RemTrip-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8
| L9 | L10
TimeZone
Time Zone
(UTC+0) - Greenwich Dublin Edinburgh Lisbon
London | (UTC+1) - Amsterdam Berlin Bern
Rome Stockholm Vienna | (UTC+2) - Athens
Bucharest Cairo Instanbul | (UTC+3) - Addis
Abeba Baghdad Moscow Nairobi S.Petersburg
| (UTC+4) - Baku Dubai Mauritius Samara
Tbilisi | (UTC+5) - Karachi Maldives Tashkent
Yekaterinburg | (UTC+6) - Almaty Dhaka Omsk
| (UTC-1) - Azores CapoVerde | (UTC-2) - Mid
Atlantic | (UTC-3) - Brasilia BuenosAires
Georgetown Greenland | (UTC-4) - AtlanticTime
LaPaz Manuas Santiago | (UTC-5) - EasternTi-
me (US Canada) Indiana | (UTC-6) - CentralTime
(US Canada) CentralAmerica
Daylight saving time
Disable | Europe | Russia | Jordan | Syria |
Egypt
Virtual Outputs - VOUT
Settings
Start dropout time for voltage protections tV s 0.00 ... 30.00 step = 0.01
Trip reset tTrip s 0.00 ... 30.00 step = 0.01
VOUT1
Type
Start | Trip | Plc | Input
Start
UE>> | 27V1 | 59V2 | U< | TEST_START
Trip
U<TR | U<<TR | U>TR | U>>TR | UE>TR |
UE>>TR | Th1>TR | Th2>TR | Th3>TR | Th4>TR
| Th5>TR | Th6>TR | Th7>TR | Th8>TR | 74TCS-
TR | BF-TR | TEST_TRIP | U1<TR | Uavg>TR |
U2>TR | f>TR | f>>TR | f<TR | f<<TR | f<<<TR |
f<<<<TR | df>TR | df>>TR | df>>>TR | df>>>>TR
Input Mask1
IN1 | IN2 | IN3 | IN4 | IN5 | IN6 | IN7 | IN8 | IN9
| IN10 | IN11 | IN12 | IN13 | IN14 | IN15 | IN16
| IN17 | IN18 | IN19 | IN20 | IN21 | IN22 | IN23
| IN24 | IN25 | IN26 | IN27 | IN28 | IN29 | IN30
| IN31 | IN32
Input Mask2
IN33 | IN34 | IN35 | IN36 | IN37 | IN38 | IN39 |
IN40 | IN41 | IN42
VOUT2
Type
Start | Trip | Plc | Input
Start
UE>> | 27V1 | 59V2 | U< | TEST_START
