NV10P - Manual - 01 - 2015
APPENDIX
Description Parameter Unit Setting range
Communication
RS485
Protocol
MODBUS | IEC60870-5-103
Address
1 ... 254 step = 1
Baudrate RS485
1200 baud | 2400 baud | 4800 baud | 9600 baud
| 19200 baud | 38400 baud | 57600 baud
Ethernet
IP host address
IP net mask
IP gateway
Autonegotiation OFF | ON
Network Services
NTP
General
Enable
OFF | ON
Type
Local Network | Internet | User
NTP synchronization LED
None | START | TRIP | L1 | L2 | L3 | L4 | L5
Internet Type
NTP Server
Zurich(Europe) | Berlin(Europe) | Italy(Europe)
| Fukuoka1(Japan) | Fukuoka2(Japan) |
Pushchino(Russia) | Lagos(Nigeria) | South
Africa
User Type
NTP Server address
Network management
Enable
OFF | ON
Type
Multicast | Broadcast
Multicast address
Broadcast address
Rx port 0 ... 20000 step = 1
Tx port
0 ... 20000 step = 1
TimeToLive(Multicast)
0 ... 20 step = 1
RPC
TCP
Server
Enable
OFF | ON
Led client(s) connected
None | START | TRIP | L1 | L2 | L3 | L4 | L5
CONN1
VOUT/IN PAIR
Pair_1 Local Vout
VOUT1 | VOUT2 | VOUT3 | VOUT4 | VOUT5 |
VOUT6 | VOUT7 | VOUT8 | VOUT9 | VOUT10
| VOUT11 | VOUT12 | VOUT13 | VOUT14 |
VOUT15 | VOUT16 | NONE
Pair_1 Remote Vin
VIN1 | VIN2 | VIN3 | VIN4 | VIN5 | VIN6 | VIN7
| VIN8 | VIN9 | VIN10 | VIN11 | VIN12 | VIN13 |
VIN14 | VIN15 | VIN16 | VIN17 | VIN18 | VIN19
| VIN20 | VIN21 | VIN22 | VIN23 | VIN24 |
VIN25 | VIN26 | VIN27 | VIN28 | VIN29 | VIN30
| VIN31 | VIN32 | NONE
Pair_2 Local Vout
VOUT1 | VOUT2 | VOUT3 | VOUT4 | VOUT5 |
VOUT6 | VOUT7 | VOUT8 | VOUT9 | VOUT10
| VOUT11 | VOUT12 | VOUT13 | VOUT14 |
VOUT15 | VOUT16 | NONE
