14
• UsingtheM-864DinconjunctionwiththeexternalcontroldeviceviaLAN(Ethernet)
• UsingmultipleM-864Dunits(upto5M-864Dunits)
In this event, Preset memory switching interlocks among up to 5 M-864D units.
• UsingmultipleM-864Dunits(upto5units)inconjunctionwiththeexternalcontroldeviceandZMRemote
controller to be directly connected, and a PC and external device via LAN.
M-864D
Switching hub
External control device
M-864D
Switching hub
M-864D
Switching hub
ZM Remote
controller
PC
External control device
External control device
Note
Only a single M-864D can
be controlled from a PC.
