27.2. ZM-9011
Power Source 24 V DC (supplied from M-864D)
Current Consumption 50 mA or less
Terminal Removable terminal block (10 pins)
Connection Cable Shielded CPEV cable (paired data line and paired power line) or
Category 5 twisted pair cable for LAN (CAT5-STP)
Operating Section 4 function buttons
Indicator 4 operation indicators (green LEDs)
Operating Temperature 0to+40°C(32–104°F)
OperatingHumidity 35to80%RH(nocondensation)
Finish Surface-treated steel panel, white, paint
Dimensions 72 (w) x 127 (h) x 49.5 (d) mm (2.83” x 5” x 1.95”)
Weight 160 g (0.35 lb)
Note: Thedesignandspecicationsaresubjecttochangewithoutnoticeforimprovement.
• Accessories
Box mounting screw (No. 6-32UNC x 30) ...... 2
Box mounting screw (M4 x 30) ....................... 2
Panel mounting screw .................................... 2
Removable terminal plug (10 pins) ................. 1
Note: Since no electrical box is supplied with the unit, prepare it separately.
• Accessories
[CE/CE-AU/CE-GBversion]
Power supply cord (2 m or 6.56 ft) ...................... 1
Removable terminal plug (3 P) .......................... 12
Large type removable terminal plug (10 P) ......... 2
Small type removable terminal plug (10 P) .......... 1
Fader gang bar*
1
................................................. 4
Rack mounting screw .......................................... 4
Protective cover ................................................... 1
CD-ROM (containing M-864D PC software) ....... 1
[CUversion]
Power supply cord (2 m or 6.56 ft) ...................... 1
Removable terminal plug (3 P) .......................... 12
Large type removable terminal plug (10 P) ......... 2
Small type removable terminal plug (10 P) .......... 1
Fader gang bar*
1
................................................. 4
Protective cover ................................................... 1
CD-ROM (containing M-864D PC software) ....... 1
*
1
Allows side-by-side two fader knobs to be linked and operated together as one fader.
• Optional products
Remotecontrolpanel:ZM-9011/9012/9013/9014
AC adapter: AD-246*
2
*
2
Consult your TOA dealer when using an equivalent adapter.
