Function InputPAD(−16dB)control,lowcut(cutofffrequency:100Hz)control,
analogoutputattenuator(−6dB,−12dB,−18dB,−24dB,−36dB,−42dB) control,
system lock function, stereo summing function, Control knobs (3 rotary encoders)
Front Panel Section
Input Level Indicator 3-point LED, 12 channels (each monaural input channel, stereo 1L, 1R, 2L, 2R)
Output Level Indicator 8-point LED, 4 channels (each output channel)
Auto Resonance Control
(ARC) Measurement
ARC switch x 1, ARC operation indicator x 1
Feedback Suppressor
(FBS) Function
Feedback Suppressor switch x 8, Feedback suppressor indicator x 8
Low Cut Filter Low cut switch x 8, Low cut indicator x 8
Summing Output Monaural summing switch x 2, Monaural summing indicator x 2
Tone Control BASS,MID,TREBLE/Settablewithcontrolknobs,10channels
(each monaural input channel, stereo 1L, 1R, 2L, 2R)
Monaural Input, Analog
Setting
Gainsetting,PADON/OFF,PhantompowerON/OFF
Settable with control knobs, 8 channels (each monaural input channel)
Stereo Input, Analog
Setting
Trim setting
Settable with control knobs, 6 channels (1-A, 1-B, 1-C), (2-A, 2-B, 2-C)
REC OUT, Gain Setting Gain setting
Settable with control knobs, 2 channels (REC OUT L, REC OUT R)
Preset Memory Switching Preset memory key x 4, Preset memory indicator x 4
System Lock System lock key x 1, System lock indicator x 1
Operation Status Indication Operation status indicator x 3
Function Setting Section Control knob x 3, 10-point position indication LED x 3, Tone control mode
indicator x 1, Gain control mode indicator x 1, Trim control mode indicator x 1
Analog Volume Fader Input volume fader x 10, Output volume fader x 4,
2 faders linkable with supplied gang bar
Control Section
Contact Input 8 channels, open voltage: 24 V DC, short-circuit current: 5 mA,
removable terminal block (10 P)
Contact output 8channels,no-voltagemakecontact,contactcapacity:24VDC/100mA,
removable terminal block (10 P)
Remote Control Panel 2 channels, Maximum number of units: 8 units per channel
24 V DC input x 2, termination switch x 1, removable terminal block (10 P)
Maximum total cable length (star wiring): 800 m or 870 yd (total for 2 channels)
Maximum cable length (daisy chain wiring): 400 m or 435 yd per channel
Note: In daisy chain wiring, the number of units differs depending on the cable length.
Star wiring and daisy chain wiring cannot be used together.
Type of cable: Shielded CPEV cable (a pair of data cable and a pair of power supply
cable) or shielded Cat 5 twisted pair cable for LAN (CAT5-STP)
Network NetworkI/F:1channelof10BASE-T/100BASE-TX (auto-negotiation)
RJ45 connector, connection via switching hub
Networkprotocol:TCP/IP
Connection cable: Shielded Cat. 5 or higher twisted pair cable for LAN
(Cat. 5-STP or better)
Maximum cable length: 100 m or 110 yd (between M-864D and switching hub)
Operating Temperature 0 to 40 ºC (32 to 104 ºF)
OperatingHumidity 90%RH(nocondensation)
Finish Panel: Aluminum, hairline, black, Case: Surface-treated steel plate
Dimensions 482.6 (w) x 177.1 (h) x 157.2 (d) mm (19” x 6.97” x 6.19”)
Weight 5.1 kg (11.24 lb)
Note: Thedesignandspecicationsaresubjecttochangewithoutnoticeforimprovement.
