18.5. Confirming the ARC Function Setting Status
18.5.1. Confirming the setting status by the ARC operation indicator status
TheARCON/OFFsettingcanbecheckedbytheARCoperationindicatorstatus.
Lit
Status of the ARC operation indicator
Unlit
ARC filter enabled ARC filter disabled
18.5.2. Confirming the setting status through the ARC switch operation
WhentheARCoperationindicatorislighting,theARClter-setoutputchannelcanbecheckedthroughthe
ARC switch operation.
HolddowntheARCswitchfor1secondormore.
AlltheoutputlevelindicatorsoftheARClter-setoutputchannelash.
M-864D
ARC operation indicator
ARC switch
Hold down for 1 second
or more.
Output level indicator
All indicators flash
Note
Useane-tippedobjectto
press in the ARC switch.
