27.3. ZM-9012
Power Source 24 V DC (supplied from M-864D)
Current Consumption 50 mA or less
Terminal Removable terminal block (10 pins)
Connection Cable Shielded CPEV cable (paired data line and paired power line) or
Category 5 twisted pair cable for LAN (CAT5-STP)
Operating Section 1 volume control knob
Indicator Volume set position indicator (7-point green LED)
Operating Temperature 0to+40°C(32–104°F)
OperatingHumidity 35to80%RH(nocondensation)
Finish Surface-treated steel panel, white, paint
Dimensions 72 (w) x 127 (h) x 57.5 (d) mm (2.83” x 5” x 2.26”)
Weight 160 g (0.35 lb)
Note: Thedesignandspecicationsaresubjecttochangewithoutnoticeforimprovement.
• Accessories
Box mounting screw (No. 6-32UNC x 30) ...... 2
Box mounting screw (M4 x 30) ....................... 2
Panel mounting screw .................................... 2
Removable terminal plug (10 pins) ................. 1
Note: Since no electrical box is supplied with the unit, prepare it separately.
27.4. ZM-9013
Power Source 24 V DC (supplied from M-864D)
Current Consumption 50 mA or less
Terminal Removable terminal block (10 pins)
Connection Cable Shielded CPEV cable (paired data line and paired power line) or
Category 5 twisted pair cable for LAN (CAT5-STP)
Operating Section 8 function buttons
Indicator 8 operation indicators (green LEDs)
Operating Temperature 0to+40°C(32–104°F)
OperatingHumidity 35to80%RH(nocondensation)
Finish Surface-treated steel panel, white, paint
Dimensions 120 (w) x 127 (h) x 50.5 (d) mm (4.72” x 5” x 1.99”)
Weight 300 g (0.66 lb)
Note: Thedesignandspecicationsaresubjecttochangewithoutnoticeforimprovement.
• Accessories
Box mounting screw (No. 6-32UNC x 30) ...... 4
Box mounting screw (M4 x 30) ....................... 4
Panel mounting screw .................................... 4
Removable terminal plug (10 pins) ................. 1
Note: Since no electrical box is supplied with the unit, prepare it separately.
