15. SPECIFICATIONS
[MX-6224D]
Power Source 220 V – 240 V AC, 50/60 Hz
Power Output 240 W x 2 channels (100 V, 42 Ω, rated output)
Power Consumption 100 W (according to IEC60065), 570 W (at rated output, both channels)
Amplication System Class D, Output transformerless galvanic isolated output
Frequency Response 50 Hz – 20 kHz, ±3 dB (at 1/3 rated output, rated load, from power amplier input)
Distortion 1 % or less (at 1 kHz, 1/3 rated output power)
Input MIC 1: –50 dB* (24 V phantom powered)/–60 dB* (phantom power OFF)
600 Ω, electronically-balanced, ø6.3 mm phone jack (3P: balance)
MIC 2 – 4: –66 dB*, 200 Ω, electronically-balanced,
XLR-3-31 type and ø6.3 mm phone jack (3P: balance)
(either one usable)
MIC 5 – 6: –60 dB*, 600 Ω, electronically-balanced,
XLR-3-31 type and ø6.3 mm phone jack (3P: balance)
(either one usable)
AUX 1: –10 dB*, 10 kΩ mixed monaural, unbalanced, RCA pin jacks (1 pair)
AUX 2: –20 dB*, 10 kΩ mixed monaural, unbalanced,
ø3.5 mm mini jack (3P: stereo)
Power amplier input:
0 dB*, 10 kΩ, unbalanced,
RCA pin jacks (1 each for ROOM and OUTSIDE outputs)
Output Speaker output: 2 zones, 100 V (42 Ω), galvanic isolated balanced, M4 screw
terminal
Recording output: 0 dB*, 600 Ω monaural, unbalanced, RCA pin jacks (1 pair)
Effect bus output: 0 dB*, 600 Ω monaural, unbalanced, RCA pin jacks (1 pair)
Preamplier output: 0 dB*, 600 Ω monaural, unbalanced,
RCA pin jacks (1 each for ROOM and OUTSIDE outputs)
Phantom Power ON/OFF switchable for MIC 1 and XLR-3-31 type connectors of MIC 2 – 6
Signal to Noise Ratio 60 dB or more (All volume controls: min.)
Controls 6 Microphone volume controls, 2 AUX volume controls,
1 ROOM output switch, 1 ROOM volume control, 1 OUTSIDE output switch,
1 OUTSIDE volume control, 1 Effect control (0 to 100 %) of Effect bus,
1 Effect preset type selection switch (DOME/HALL/PLATE/DELAY),
1 Effect Room size/Delay time selection switch (L/M/S/OFF),
1 Effect output selection switch (OFF/ON),
1 MIC 5 – 6 effect switch,
1 Low EQ control (±15 dB, 80 Hz) for MIC 1 – 6,
1 Mid EQ control (±15 dB, 2.5 kHz) for MIC 1 – 6,
1 High EQ control (±15 dB, 12 kHz) for MIC 1 – 6,
1 Speaker EQ (TC-631M, TC-651M) switch for OUTSIDE output,
1 Speaker EQ (BS-1030B, BS-1030W) switch for ROOM output, 1 Power switch,
1 Phantom switch for MIC 1, 1 Phantom switch for MIC 2 – 6 (XLR-3-31)
Indicators SLEEP indicator
Output Level meters (2 points, –20 dB and 0 dB) for ROOM and OUTSIDE
Protection indicators for ROOM and OUTSIDE ampliers
Output indicators for ROOM and OUTSIDE
EFFECT indicator for MIC 1 – 6
Ventilation Natural air cooling
Operating Temperature 0 to 40 ºC (32 to 104 ºF)
Operating Humidity 35 to 80% RH (no condensation)
Dimensions 420 (w) x 99.8 (h) x 360.6 (d) mm (16.54" x 3.93" x 14.2")
Installation Method Desktop mount, Rack mount with mounting bracket MB-25B (option)
Weight 6.1 kg (13.45 lb)
Finish Front Panel: Aluminum, black, alumite
Case: Steel plate, black, paint
* 0 dB = 1 V
Note: The design and specications are subject to change without notice for improvement.
•Accessories
Power supply cord ..................................... 1 Sticker for Arabic indication ....................... 1
