10.2.3. Settings when using the effector for OUTSIDE zones
The effector can also be enabled or disabled (ON/OFF) for OUTSIDE zone output (default setting: OFF).
Step: To apply the sound effect to broadcasts made to OUTSIDE zones,
set the Outside Zone Output Effect switch to the ON position.
Outside zone output effect switch
The following table shows the effector status of each zone output
when the Outside Zone Output Effect Switch is set to the ON or
OFF position:
OFF ON
ROOM zone output Effector enabled Effector enabled
OUTSIDE zone output Effector disabled Effector enabled
10.3. Speaker Equalizer Settings
The unit’s built-in speaker equalizer can be used to adjust the following TOA speakers for optimal sound quality:
For ROOM zone: BS-1030B, BS-1030W
For OUTSIDE zone: TC-631M. TC-651M
To use this function, set the Equalizer switch ON for the desired zone(s).
OFF ON
SP EQ
For OUTSIDE zone For ROOM zone
