1 NOMENCLATURE AND FUNCTIONS
1-1
1 NOMENCLATURE AND FUNCTIONS
1.1 Nomenclature
Power supply
connector
Base fixing screw
Optical plummet
telescope
Handle
Objective lens
Laser aperture
(for auto-tracking)
(GPT-8000A series)
Base (Model 5)
Instrument center
mark
Leveling screw
Serial Signal
Connector-1(6pin)
Sighting collimator
Handle fixing knob
Display window
Operation keys
Battery BT-56Q
Card cover lever
Instrument height
mark
Tra c king indicator
(GPT-8000A series)
Point guide
(GPT-8000 series)
Laser aperture
(for optical
communication)
(GPT-8000A series)
The caution labels are pasted up GPT-8000A series and Laser plummet model which describe
the warning of laser beam.
Refer to "Laser Safety" and "Laser plummet model" about label positions and their shapes
.
