The following data will be output at each mode.
●
The display and the output at the coarse (1mm) mode are the same as the contents above.
● Output at the coarse (10mm) mode is displayed as distance data only (HD, VD or SD).
Operating procedure Display
1
Operate the data collector to measure the distance.
Measurement will be started.
2
The result will be shown and transferred to the Data
Collector.
3
The mode will automatically return to the distance
measurement mode.
Mode Output
Angle mode (V,HR or HL) (V in percent) V, HR (or HL)
Horizontal distance mode (V, HR, HD, VD) V, HR, HD, VD
Slope distance mode (V, HR,SD) V, HR, SD,HD
Coordinate mode N, E, Z, HR
V : 90°10'20"
HR: 120°30'40" PSM 0.0
HD: < PPM 0.0
VD: (m) *F.R
MEAS MODE VH SD NEZ P1
↓
V : 90°10'20"
HR: 120°30'40" PSM 0.0
HD: 10.1234 PPM 0.0
VD: 1.234 (m) *F.R
REC > > >
V : 90°10'20"
HR: 120°30'40" PSM 0.0
HD: 10.1234 PPM 0.0
VD: 1.234 (m) *F.R
MEAS MODE VH SD NEZ P
1
↓
4.4 DATA OUTPUT
Result of measurement is transferred to Data Collector (FC series) from GPT-8000A/8000 series.
[Example: Distance measurement mode]
Confirm the distance measurement mode.
To Next Page
