5 PROGRAM MODES
5-13
11
Rotate the vertical tangent screw, and sight
ground point G.
Sight G
12
Press [F6] (SET) key, line height (LH) and
horizontal distance (Off) are displayed.
[F6]
●
To finish the measurement, press the [F1](EXIT) or [ESC] key.
● To return to operation procedure
9
, press the [F2](VD) key.
● To return to operation procedure
11
, press the [F6](NEXT) key.
The NEXT key is used when the ground point G is not clear and you would like to check another ground
point G on the same vertical line.
LINE
G-POINT
V : 90°40'20"
EXIT SET
LINE
LH: 33.765 m
Off: 27.521
m
EXIT VD NEXT
