4
If you reset the offset value, press the
[F6](INP) key and input the value. *1)
[F6]
5
Collimate prism using the horizontal motion
clamp and horizontal tangent screw.
Press the [F1](MEAS) key. *2)
The offset measurement data will be shown.
Collimate
P
[F1]
6
To show the slope distance of point A
0
, press
the [F2](SD) key.
[F2]
7
To s how t h e coordinates, press the [F3](NEZ)
key. *3)
[F3]
*1) To skip the input, press the [F1](OK) key.
*2)To set the prism height or instrument height, press the [F5](HT) key.
*3)To repeat the offset measurement, press the [F1](NEXT) key. The display will return to step 5.
DIST. OFFSET
dFR : 0.000 m
dRL : 0.000 m
EXIT BS
DIST. OFFSET
HD: m
MEAS HT
DIST. OFFSET
HR: 30°00'00"
HD: 20.000 m
VD: 0.000 m
NEXT SD NEZ REC
DIST. OFFSET
V : 90°00'00"
HR: 30°00'00"
SD: 20.000 m
NEXT HD NEZ REC
DIST. OFFSET
N : 17.321 m
E : 10.000 m
Z : 0.000 m
NEXT SD HD RE
C
