2
Press the [F2] key to select [2PARAMETER
(CABLE)].
Speed setting screen will appear.
[F2]
3
Press the [F3](↑) or [F4](↓) key to select baud
rate then press the [F1](SET) key to decide.
[F3]
or
[F4]
[F1]
4
Set bit format in the same way.
[F3]
or
[F4]
[F1]
5
Set DELIMITER (Terminate) in the same way.
[F3]
or
[F4]
[F1]
6
Set RTS in the same way.
7
Set REC TYPE in the same way.
[F3]
or
[F4]
[F1]
● To cancel the setting, press the [F6](EXIT)key or the [ESC] key.
SPEED
9600
SET
↑ ↓ EXIT
BIT FORMAT
D8 S1 NONE
SET
↑
↓
EXIT
TERMINATE
ETX
SET ↑ ↓ EXIT
RTS
Hi
SET ↑ ↓ EXIT
REC TYPE
REC-A
SET
↑ ↓
EXIT
Setting
1 CABLE/RADIO MODEM/RC
2
PARAMETER(CABLE)
3 PARAMETER(RC)
4 PARAMETER(RADIO MODEM)
(3)Setting Parameters of RC
Attach the remote controller handle unit RC-2H and set the parameters for communication with
the remote controller system RC-2II.
Parameters
1) Channel
Sets communication channel
The same channel must be set for GPT-8000A series and RC-2RII.
Set channels : 1, 2, 3
2) DELIMITER (Terminate)
Selecting CR (Carriage return), or LF (Line feed) will be added at the end of data.
Set items:
ETX, ETX+CR, ETX+CRLF
3) Retry
This is a method to retry setting for sending data again during communication with remote
controller RC-2II.
Set items: Standard,Divided
Standard:Gives good for fast communication.
This is offered in normal condition.
Divided: Using in bad condition such in long distance, bad condition of sight, strong
heat simmer, or happens cut off the optical path, in such cases it takes long
time for communication or results failure. You are offered to set [Divided] item.
