Topcon HiPer SR - Charging the Batteries

Getting Acquainted
Cables
13
P/N:1000737‐01
PowerAdapter
Chargesthereceiverwhenconnectedtoagrounded
outletandthepowercharge rcable.
p/n22‐034101‐01
PowerChargerCable
Connectsthepoweradaptertoagroundedoutlet.Sever‐
aloptionsareavailableforthepowerchargercablebased
onyourcountry.Ifthekitdoesnotincludeapower
chargercable,contactyourTopcondealer.Refertothe
thesepartnumbersforavailablepowerchargercables:
p/n14‐008052‐01(USAconnector)
p/n14‐008054‐01(EURconnector)
p/n14‐008074‐01(AUSconnector)
p/n1000475‐01(BRLconnector)
PowerandSerialCable
Connectsthereceivertothepoweradapterthroughthe
SAEconnectorandanexternaldevicethroughtheRS‐232
port(DB9connector).Typically,thi scableisnotshipped
withthestandardkitconfigurationbutisavailableto
purchaseseparately.
p/n:1000182‐01
Table1.ReceiverCables
Cable Description Cable Illustration
