Communication LED
TheCommunicationLEDdisplaysthestatusofthecellularandBluetoothactivity.Thefollowingtablesdescribethe
communicationactivityforthreeusecases.
Bluetooth Only Status
Cellular and Bluetooth Status
Table5.BluetoothLEDPatterns
LED Color Description
AsingleBluetoothconnectionisestablished.
MultipleLongLINKconnectionsareestablished.TheLED
blinksforeachconnectionevery10seconds.
Bluetoothisturnedoff.
Table6.CellularandBluetoothLEDPatterns
LED Color Description
Cellularmodemisstartingup.
Dataisbeingreceivedortransmitted.
