Receiver Status LEDs
TherearefourstatusLEDstoprovideyouinformationaboutthebatterylife,trackedsatellites,memorycapacity,andBluetooth
wirelessconnectivity.ThissectiondescribesthecolorandbehaviorofeachLED.
Tracking Status LED
ThetrackingstatusLEDdisplayshowmanysatellitesthereceiveristracking.
Table 3. Status LED Patterns
LED Color Description
1 OneblinkpertrackedGPSsatellite.
2 OneblinkpertrackedGLONASSsatellite.
3 Oneblinkwhentherearenotracked
satellitesorsolutions.ItisOffotherwise.
