Topcon HiPer SR - Recording and Communication LEDs

Display Panel Operations
ReceiverStatusLEDs
20
P/N:1000737‐01
Recording LED
ThememoryLEDindicatesifdataisbeingwrittentomemoryanddisplayshowmuchmemorythereceiverhasavailablefor
recording.
Table4.RecordingLEDPatterns
Display Function Description
Fileloggingisinprogress.Eachblink
indicatesdataisbeingwrittento
memory.
Thefileisclosed.Asolidlightindicates
nodataisbeingrecorded.
Erasingmemory
AlternatinggreenandredLEDsindicate
allfilesarebeingdeleted.
Formattingmemory
AlternatingredandyellowLEDsindicate
thememorycardisbeinginitializedor
formatted.
Missingorfaulty
memory
TheLEDisoff.
