Cables
TheHiPerSRpackageincludesapowersupplycable,aUSBcable,andapoweradapter.Table1describesthecablesincluded
withyourreceiver.
Alignthekeywayswhenconnectingthepower/serialcabletothereceiverport.Turnthecablelockclockwise
untilitclickstosecurethecableinplace.Todisconnectthecable,turnthelockcounter ‐clockwise,andthen
gentlyremovethecable.
Table1.ReceiverCables
Cable Description Cable Illustration
ReceiverPowerCable
Connectsthereceivertothepoweradapterthroughthe
SAEconnector.
p/n:1000181‐01
USBCable
Connectsthereceivertoanexternaldevice(controlleror
computer)fordatatransferandreceiverconfiguration.
p/n14‐008081‐01
