Topcon HiPer SR - Loading New Firmware

Configuring the Receiver
LoadingNewFirmware
32
P/N:1000737‐01
Loading New Firmware
Receiverboardfirmwareisreleasedasacompressedfilethatyoudownloadanddecompress.Thisfilecontainsthefollowing
twofiles:
• ramimage.ldr–theReceiverboardRAMfile
• main.ldp–theReceiverboardFlashfile
Touploadfirm warefilestothereceiver:
1. ConnectthereceivertoacomputerusingthePowerandSerialcablereceiveraccessory(p/n:100182‐01).
2. ClickDeviceApplicationModeFirmwareLoading.
OnlyusethePowerandSerialcabletouploadfirmwaretothereceiver.UsingaUSBorBluetoothconnection
touploadfirmwarecoulddamagethereceiver.Thenextfirmwarerelease,4.0SR,wi llsupportUSBor
Bluetoothconnectionsforfirmwareuploads.Seewww.topcontotalcare.comforfirmwareupdates.
