Topcon HiPer SR - Battery LED

Display Panel Operations
ReceiverStatusLEDs
24
P/N:1000737‐01
Battery LED
TheBatteryLEDindicatestheremainingchargeoftheinternalbatteries.Whenanexternalpowersourceisutilized,theLED
turnsgreenandbeginstoblinkifthebatteriesbegintocharge.See
Table8formoreinformation.
Table8.BatteryLEDPatterns
LED Color Description
THE RECEIVER IS ON; INTERNAL BATTERIES IN USE
Thechargeisgreaterthan50percent.
Thechargeisgreaterthan15percent.
Thechargeislessthan15percent.
THE RECEIVER IS ON; EXTERNAL POWER IN USE; PWR LED IS SOLID GREEN
Anexternalpowersourceisinuse,andtheinternalbatteriesarefullycharged.
Theinternalbatteriesareatgreaterthan50%capacity;thebatteriesarebeingcharged.
Theinternalbatteriesareatgreaterthan15%capacity;thebatteriesarebeingcharged.
Theinternalbatteriesareatlessthan15%capacity;thebatteriesarebeingcharged.
THE RECEIVER IS OFF
Thereceiverisconnectedtoanexternalpowersource,andthebatteriesarefullycharged.
Thereceiverisconnectedtoanexternalpowersource,andthebatteriesarebeingcharged.
